Series 650MA Series Info EDP# 94067 4x75x25mm SQ 4FL 25mm F/L *TiALN*

Flutes Flute Diameter Flutes Length Shank Diameter Neck Diameter Overall Length Reach Length _(L.B.S.) Neck Length Behind Flutes Corner Radius End
Type Flat Weight _(lbs) Coating
4 4.0000 25.0000 4.0000 - 75.0000 - - - SQ - 0.0300 TIALN

DETAILS

4x75x25mm SQ 4FL 25mm F/L *TiALN*

General Purpose
Extra Length - Square End - 4 Flutes - TiAlN Coating
Solid submicron grain carbide end mill - center cutting
Extended reach
Dry or semi-dry machining
Can be modified with a neck within 48 hours
Extremely versatile

TOLERANCES

flute dia. +0.000-0.050mm
shank dia. h6

TECH PAGES

Fractional
Metric
Catalog

QUANTITY ON HAND

usa 100+
uk 88

PRICING

QUANTITY: 1-11 12-24 25-49 50-100
PRICING: $26.28 $25.14 $23.99 $22.85

how to buy >

Not quite what you’re looking for? Request a Special Tool Quote
