Series 545BA Series Info EDP# 21324 5x65mm BALL 4FL 15MM F/L HIGH RC *DURANA*

Flutes Flute Diameter Flutes Length Shank Diameter Neck Diameter Overall Length Reach Length _(L.B.S.) Neck Length Behind Flutes Corner Radius End
Type Flat Weight _(lbs) Coating
4 5.0000 15.0000 6.0000 - 65.0000 - - - BALL - 0.0600 DURANA

DETAILS

5x65mm BALL 4FL 15MM F/L HIGH RC *DURANA*

For Inconel, Tool Steels, Hardened Die Mold >40Rc
Ball End - DURANA Coating
Solid submicron grain carbide end mill - center cutting
High performance tool for use in high Rockwell and difficult to machine materials

TOLERANCES

flute dia. +.000-.002" (+0.000-0.050mm)
shank dia. h6
ball radius +.000-.001" (+0.000-0.025mm)

TECH PAGES

QUANTITY ON HAND

usa 46
uk 12

PRICING

QUANTITY: 1-11 12-24 25-49 50-100
PRICING: $30.02 $28.71 $27.41 $26.10

how to buy >

Not quite what you’re looking for? Request a Special Tool Quote
